CNLINKO 12v Dc Power Supply Connector Waterproof 5 Pin Circular Power Male Female Plug Socket Connector

Name: CNLINKO 12v Dc Power Supply Connector Waterproof 5 Pin Circular Power Male Female Plug Socket Connector
Brand: Cnlinko
Price: 6.18 USD

Buy cheap CNLINKO 12v Dc Power Supply Connector Waterproof 5 Pin Circular Power Male Female Plug Socket Connector product

Place of Origin : Guangdong, China

Brand Name : Cnlinko

Model Number : YM-20-C05PE-01-001,YM-20-J05SX-01-001

Certification : UL,CE,ROHS,CCC,ISO9001

MOQ : 2

Price : $6.18-7.18

Type : Signal

Application : Audio & Video

Gender : male and female, Female +male

Protection level : IP65/IP67

Pin : 2-12pin

Current rating(A) : 10A

Shell & Insulated Parts : High Performance Engineer Plastic

Hardware Matel : Zinc Alloy (pearl hard chromium)

Connecting mode : plug/unplug

Operating voltage : 500V

Contact Now

Product Description

Specifications

Specifications
Connecting mode	Latching Lock connect
Protection level	IP65/IP67
Cable specification	1.0mm2 ~ 1.5mm2 /18~16AWG
Diameter range	Φ7mm ~Φ10mm
Contact diameter×Qty	Φ1.8×5
Current rating(A)	10A
Temperature rise	20A contact temperature below 30℃ 25A contact temperature below 40℃ 30A contact temperature below 50℃
Operating voltage(AC.V.rms)	250V
Withstanding voltage(AC.V)1min	2500V
Contact resistance	<1mΩ
Insulation resistance	>500MΩ
Durability	≥500 mating&unmating cycles
Temperature rating	-40°C~80°C
Method of connecting cable	Soldering
Prevent the combustion level	UL94-V0
Material
shell & Insulated parts	High performance engineering plastics
Hardware metal	Zinc alloy(pearl hard chromium)
Contact pin	Copper alloy(gold-plated 4U)
Spring	Stainless steel
Sealing	Silica gel
Main characteristics
Sealed against dust and fluid (IP65/IP67)
Vibration resistance,impact resistance,stretching resistance
1/4 bayonet connect; socket with cover
Application industries
Stage equipment - The smart grid
Medical equipment - Server
Solar energy equipment - Ship equipment
Electric power equipment - Vehicle equipment
Communications equipment - Heavy machinery
